High availability

High availability restarts a machine on a surviving node when the node running it fails. It is configured under Datacenter → HA.

This page covers HA in depth. If you have not yet built a cluster, start with Clustering and high availability — a cluster is a prerequisite.

Before you turn it on

Requirement	Why
Three or more nodes	Two nodes cannot form a majority, so a failure leaves the survivor unable to act.
Storage the other nodes can reach	HA restarts a machine; it does not copy disks. Use shared storage, or replication.
Synchronised clocks	Drift breaks cluster authentication — see Fixing “Authentication failed! (401)”.
A licence that covers high availability	Required to add an HA resource.

Storage is the requirement people skip

A machine whose disk lives only on local storage on the failed node cannot be started anywhere else. Either put it on storage every node can see, or replicate it so a recent copy already exists elsewhere — and accept that the machine resumes from the last replicated point, not from the instant of failure.

Reading the status panel

Datacenter → HA shows a status list above the protected machines.

Row	Normal reading
quorum	OK — a majority of nodes can see each other
fencing	standby when nothing is protected yet

“fencing: standby” is not a fault

On a cluster with no HA resources defined, the manager has nothing to protect and its watchdog sits idle. The status changes once you add the first machine.

Protecting a machine

1. Open Datacenter → HA.
2. Under the resource list, click Add.
3. Choose the machine in VM.
4. Set Request State to started.
5. Adjust the fields below if the defaults do not suit.
6. Click Add.

You can also do this from the machine itself with More → Manage HA, or by ticking Add to HA while creating it.

The fields

Field	What it does
Max. Restart	How many times to retry starting on the same node before giving up on that node.
Max. Relocate	How many times to try a different node before the machine is left in an error state.
Failback	Whether the machine returns to its preferred node once that node is healthy again.
Auto-Rebalance	Whether the cluster may move this machine to even out load.
Request State	What the cluster should aim for — usually started.

Failback causes a second interruption

Coming back means stopping the machine where it is running and starting it on the original node. If the machine is more sensitive to interruption than to which node it runs on, leave failback off and move it back yourself during a maintenance window.

Affinity rules — controlling placement

Datacenter → HA → Affinity Rules decides where machines are allowed or preferred to run.

Two kinds of rule:

• Machine to node — this machine prefers, or requires, these nodes. Use it when only some nodes have the hardware, network or licensing a machine needs.
• Machine to machine — keep these together, or keep these apart. Keeping a pair apart is what stops a single node failure taking out both halves of a redundant service.

Each rule has a Strict setting, and it changes the meaning completely:

Strict	Behaviour
Off	A preference. The cluster honours it when it can, and ignores it rather than leave the machine down.
On	A requirement. If it cannot be satisfied, the machine does not start at all.

A strict rule can keep a machine down

Strict rules are how you express a genuine constraint — licensing, data residency, hardware that only exists on some nodes. They are also how a cluster with plenty of capacity ends up refusing to start a machine. Use strict only when running in the wrong place would be worse than not running.

Fencing

Datacenter → HA → Fencing shows how the cluster makes certain a failed node has really stopped before another node starts its machines.

This matters more than it sounds. If the original node were still running the machine and a second copy started elsewhere, both would write to the same disks. The cluster therefore waits — deliberately, not slowly — until it is certain, which is why recovery is not instant.

The built-in watchdog handles this without configuration. The list here is for sites that add external fencing devices.

Pausing HA for maintenance

Arm HA and Disarm HA at the top of the panel switch the whole mechanism on and off, leaving your resource definitions in place.

Disarm before work that would make a node look like it has failed — a firmware update, a network change, physically moving a server. Otherwise the cluster reacts to your maintenance as though it were an outage.

Remember to arm it again afterwards. A disarmed cluster protects nothing.

Where the cluster puts things

CRS Settings, also on this panel, controls how the cluster chooses a target node when placing or rebalancing machines — whether it balances on memory, on CPU, and whether it rebalances on its own.

Testing failover

Do this before you depend on it, during a maintenance window.

1. Note which node currently runs the protected machine.
2. Cut power to that node abruptly, or use its remote power control. A clean shutdown is not a realistic failure test — it lets the machine migrate gracefully instead.
3. Watch Datacenter → HA. After the cluster confirms the node is gone, the machine moves to a surviving node and starts there.
4. Check the machine’s service is actually working, not just that it is running.
5. Power the failed node back on and confirm it rejoins.

Time it

Note how long recovery takes on your hardware and write it down. That number is what you can promise, and it is the only honest input to a recovery-time objective.

If something goes wrong

What you see	What to do
A machine does not restart elsewhere	Its disks are on storage the other nodes cannot reach. Use shared storage or replication.
A machine will not start anywhere	A strict affinity rule cannot be satisfied. Relax it or fix the constraint.
The cluster will not act at all	Quorum has been lost, or HA is disarmed. Check the status list.
Recovery seems slow	It is deliberate. The cluster must be certain the node is gone before starting the machine elsewhere.
Adding a resource is refused with a licence message	The node’s licence does not cover high availability, or has lapsed. Check node → Subscription.
Machines moved on their own	Auto-Rebalance is on for those resources.

Still stuck? Contact VM2Cloud support.
